Uni Lift 9 A

Uni Lift 9 A

Item No:UNI090.010000U-9005
Uni Lift 9 A
Scissor car lift Uni Lift 3500 NT 4700 f RAL5001 blue
Scissor car lift Uni Lift 3500 NT 4700 s RAL5001 blue
More info
Customize Compare
Brief description
Item No: UNI090.010000U-9005
Lifting capacity: 9000 lb
Type Scissor Lifts
Color Black

Uni Lift 9 A

The incorporates the NUSSBAUM NT hydraulic system with precisely machined steel to create the finest alignment scissor lift in the world. This lift is the perfect solution for general repair, wheel alignment, test lanes and car reception areas.


  • Alignment:Built in rear slip plates and turntable cutouts to accommodate the largest turn plates in the market. NUSSBAUM scissor alignment lifts have the lowest profile of comparable capacity scissor racks in the market.
  • Operating Performance:Powerful lifting with our industry only oil immersed motor. This powerful motor runs in the hydraulic fluid keeping it clean, cool and permanently lubricated for up to 5x the life of a standard bolt on power unit.
  • Increased Productivity:No mechanical connection between the platforms allows free access between the scissors
  • Installation:Can be installed above-ground or in-ground
  • Flat and compact construction make the lift specially suitable for above-ground installation
  • “Safe-T-Lower” engages slow lowering and warning tone at 12″
  • Cylinders are hard chromed to increase durability and life
  • Uses less area than a similar four post, conserving valuable shop space
  • Mechanical locks standard for perfect alignment leveling at three positions
  • Available with flat or alignment ready runways
  • High performance oil-submerged power unit ensures a quiet operation and fast lifting and lowering times


Two independent hydraulic circuits ensure safe and smooth lifting of the scissors. The fully hydraulic system requires no electrical or pneumatic components. A compact oil-submerged motor controls the UNI LIFT.

Capacity 9000 lb
Platform length min 165.375 inch
Lifting height 72 inch
Platform distence min 37 inch
Drive on height 7 inch
Overall width min 84.75 inch
Power supply (V/ph) 208/230 / 1
Motor power 3 hp

Wooden crate
Packaging Wooden crate
Product Dimensions 175mm x 28mm x 20mm
Total weight 5170lb
Stackable 2
Wooden crate
Packaging Wooden crate
Product Dimensions 175mm x 28mm x 20mm
Total weight 5170lb
Stackable 2
Single use pallet
Packaging Single use pallet
Product Dimensions 51mm x 21mm x 20mm
Total weight 484lb
