The TSK 8 inground lift provides a level of flexibility not found in any other inground lift. Its design allows it to be used with a wide range of vehicles, from small cars to vans and off-road vehicles without having to drive-over the superstructure. Prevents tire/wheel damage and provides more access to vehicle under carriage.
Hydraulic cylinders are protected within a hard-chromed cylinder tubes. The lift's waterproofed canister is galvanized inside and outside for maximum protection. The canister cover can be easily removed for inspection purposes. Hard piping to the cylinder for low maintenance and long life. Crossbar for synchronization also prevents rotation of the arms. Pneumatic lock for maximum safety. Stand alone power unit with ergonomic handle for variable lowering speed. Optional, bench mounted power unit with buttons available.
Powder coated 3-stage arms with adjustable adapters for passenger cars and small vans. Arms open wider than 180° for easy access with the vehicle.
|Pick up pad height min||3.5 inch|
|Lifting height||81.5 inch|
|Power supply (V/ph)||208/230 1ph|
|Motor power||3 hp|
|Product Dimensions||104mm x 95mm x 18mm|
